Description
The PLX32-EIP-PND EtherNet/IP to PROFINET device gateway provides bi-directional data transfer between a PROFINET Controller and EtherNet/IP networks. It is a stand-alone, DIN-rail mounted unit equipped with two Ethernet ports, each operating on a different subnet, enabling flexible and efficient network integration in industrial environments.
Specifications
| Specification | Description |
|---|---|
| Power Supply | 24 VDC nominal; 10 to 36 VDC allowed; Positive, Negative, GND terminals |
| Current Load | 24 VDC nominal @ 300 mA; 10 to 36 VDC @ 610 mA maximum |
| Operating Temperature | -25°C to 70°C (-13°F to 158°F) |
| Storage Temperature | -40°C to 80°C (-40°F to 176°F) |
| Relative Humidity | 5% to 95% RH, non-condensing |
| Shock | IEC 60068-2-27; 15G @ 11 ms, 3-axis (Operational); IEC 60068-2-27; 30G @ 18 ms, 3-axis (Non-operational) |
| Vibration | IEC 60068-2-6; 5G @ 10 Hz to 150 Hz |
| Dimensions (H × W × D) | 5.38 × 1.99 × 4.38 in; 13.67 × 5.05 × 11.13 cm |
| Ethernet Ports | (2) 10/100 Mbit, full- and half-duplex, RJ45 connector |
| Electrical Isolation | 1500 Vrms at 50–60 Hz for 60 seconds, per IEC 60950:1991 Section 5.3.2; Ethernet broadcast storm resiliency ≤ 5000 ARP frames per second for ≤ 5 minutes |
| Shipped With Each Unit | 2.5 mm screwdriver; J180 power connector |
