GE IC200ALG260 Analog Input Module
GE IC200ALG260 Analog Input Module
Manufacturer: GE
Product No.: IC200ALG260
Product Type: Analog Input Module
Product Origin: USA
Payment: T/T
Weight: 0g
Shipping port: Xiamen
Warranty: 12 months
GE IC200ALG260 Analog Input Module
Technical Specifications
- Channels: 8 single-ended, one group
- Module ID: FFFF9008
- Isolation: User input to logic (optical) and to frame ground: 250VAC continuous; 1500VAC for 1 minute
- Backplane Current Consumption: 5V output: 130mA maximum
- External Power Supply: None required for module operation
- Configuration Parameters: Range select, Mode select (jumpers on carrier)
- Diagnostics: Loss of Internal Power
-
LED Indicators:
- INT PWR LED (internally-generated field power)
- OK LED (backplane power)
Features
- Voltage Inputs: Bipolar (-10VDC to +10VDC) and Unipolar (0 to 10VDC)
- Current Inputs: 4-20mA
- Resolution: 2.5mV = 8 counts in both voltage and current modes
- Filter Response: 5.0ms
- Update Rate: 0.4ms per module
- Channel-to-Channel Crosstalk Rejection: 30dB minimum
