YOKOGAWA NFCP050-SA5 CPU Module

Product Overview

• High-performance CPU module for FCN-RTU controllers

• Equipped with a 256 MHz SH-4A (SH7730) processor

• Supports IEC 61131-3 programming and Java VM

• Designed for harsh industrial environments with IP20 protection

• Multiple communication interfaces: Ethernet, RS-232, RS-422/485

• Compact and lightweight: 65.8 mm × 130 mm × 142.5 mm, 0.57 kg

• Suitable for advanced control logic and remote automation

Technical Specifications

• Processor: SH-4A (SH7730), 256 MHz

• Main Memory: 128 MB ECC RAM

• Static RAM: 1 MB ECC

• Flash Memory: 128 MB onboard

• Communication: 3 × RS-232, 1 × RS-422/RS-485, Ethernet 10/100 Mbps

• Protocols Supported: Modbus

• Power Supply: 5 V DC ±5%

• Power Consumption: 1.16 to 2.30 W

• Operating Temp: -40°C to +70°C

• Storage Temp: -40°C to +85°C

• Humidity: 5% to 95% RH (non-condensing)

• Altitude: Up to 3000 m

• Vibration Resistance: 0.15 mm P-P (5–58 Hz), 1 G (58–150 Hz)

• Corrosion Resistance: ANSI/ISA S71.04 Class G2 (G3 optional)

• Dust Tolerance: Max 0.3 mg/m³

• Protection Rating: IP20
