Woodward 5466-330 CPU-Based Control Module

Description

The Woodward 5466-330 is a CPU-based control module designed for use within the Woodward MicroNet™ Digital Control platform. It functions as the central processing unit for managing engine or turbine control systems in critical industrial applications. The module integrates processing, I/O coordination, and communications into a single unit, providing deterministic control and real-time performance.

Technical Specifications

• Functions as the primary CPU module within a MicroNet system

• Supports high-speed control algorithms for real-time response

• Equipped with onboard memory for application storage and execution

• Communication interfaces include Ethernet and RS-232/RS-485 serial ports

• Operating voltage: 18–32 VDC

• Power consumption: approx. 20 W

• Operating temperature: 0 °C to +60 °C (32 °F to 140 °F)

• Storage temperature: −40 °C to +85 °C (−40 °F to 185 °F)

• Shock and vibration tested per industrial standards

• Designed for DIN rail or chassis mount within an enclosed control panel

• Compatible with other MicroNet I/O and expansion modules
