WAGO 750-511 Digital Output Module In Stock

WAGO 750-511 Digital Output Module In Stock

Brand: WAGO
Product Type: digital output module
Payment:T/T, Western Union
Shipping Port:Jinhua China
Lead Time:1-3 Working Days
Condition: Brand New And 100% Original
Warranty: 12 months

The WAGO 750-511 is a versatile 2-channel pulse width output (PWO) module used in automation and control systems. It acts as an intermediary, converting digital signals from a higher-level controller (PLC, PC, etc.) into precisely timed pulses that control the speed, position, or intensity of various actuators.


          1. Function: Generates pulse width modulated (PWM) signals on two independent channels.
          2. Channel type: 2 x Pulse Width Output (PWO).
          3. Voltage: 24VDC nominal supply voltage.
          4. Current: 0.1A per channel maximum output current.
          5. Pulse width range: 0.1ms to 2.55ms (offering fine control over actuator behavior).
          6. Frequency: 250Hz (typical) or 100Hz (depending on the specific variant).
          7. Short-circuit protection: Yes, each channel is electronically protected.
          8. Mounting: DIN rail.
          9. Approvals: CE, UL, CSA.


                1. Compact design: Saves space in your control cabinet.
                2. Push-in spring terminals: Enables quick and tool-less wiring.
                3. LED status indicators: Provide visual feedback on the state of each channel (active/inactive).
                4. Diagnostic functions: Helps identify potential issues like overloads or short circuits.
                5. Parameterizable: Allows configuration of various settings like pulse width range, frequency, and dead time for fine-tuning actuator control.
                6. Electrical isolation: Isolates the fieldbus level (signals) from the power supply level, preventing unwanted interference and enhancing system stability.


                                                                                    1. Industrial automation: Controlling the speed of DC motors, the position of pneumatic actuators, the intensity of LED lighting, etc.
                                                                                    2. Building automation: Regulating the speed of fans, the brightness of dimmable lights, the opening/closing of motorized blinds, etc.
                                                                                    3. Machine control: Precisely positioning valves, adjusting conveyor belt speeds, controlling robotic movements, etc.
                                                                                    4. Laboratory automation: Interfacing with instruments requiring precise PWM control for experiments.
