SCHNEIDER TSXSUP702 Power Supply Module

The Schneider TSXSUP702 is a power supply module designed for the Modicon TSX Micro series of Programmable Logic Controllers (PLCs) by Schneider Electric. It provides regulated power to the PLC and its connected I/O modules, ensuring stable operation of the control system.

Overview:
Compact design: Takes up minimal space in the PLC cabinet.
Easy installation: Uses a DIN rail mounting for quick and simple setup.
LED status indicator: Provides visual cues about the power supply's operational state.

Features:
Input voltage range: Accepts a wide range of AC input voltages (likely between 85-265 VAC) to adapt to different electrical grids. This eliminates the need for an additional voltage converter in many cases.
Regulated output voltage: Provides a consistent DC voltage (typically 24 VDC) to the PLC and its I/O modules, ensuring stable operation even with fluctuations in the AC line voltage.
Overload protection: The unit has built-in overload protection to safeguard against damage from excessive current draw.
Short circuit protection: Protects the power supply and connected equipment from potential damage caused by short circuits.

Applications:
Supplying power for a wide range of Modicon TSX Micro PLCs used in various industrial automation applications. These PLCs are suited for controlling small to medium-sized machines, processes, and building automation systems.
Ideal for applications requiring reliable and stable power for the PLC system, especially when dealing with fluctuating line voltages.
