Description:
The MVI69-GSC module provides a fast and efficient method to add two fully configurable ASCII communication ports to the CompactLogix/MicroLogix platform. It does so without utilizing the processor's front port or sacrificing valuable processing time. The module integrates various devices supporting ASCII communications into the CompactLogix/MicroLogix platform via supporting ladder logic in the processor.
Features:
- Single-slot - 1769 backplane compatible
- Recognized as an Input/Output module with access to processor memory for data transfer
- Utilizes ladder logic for data transfer between module memory and processor controller tags
- Supports CompactLogix and MicroLogix 1500 LRP Controllers, except 1769-QBFC1B, 1769-L16x, and 1769-L18ER-BB1B
Functional Specifications:
- ASCII Communication ports 1 & 2 (PRT1, PRT2)
- Independently configurable ports including settings for baud rate, parity, stop bits, handshaking, and character strings up to 4096 characters in length
- Handshaking options: Hardware (RTS/CTS, DTR/DSR) and Software (XON/XOFF)
- Supports hardware handshaking control for radio, modem, and multi-drop support
- Allows storage and transfer of up to 4000 registers to/from the control processor
- Provides module error and status conditions for diagnostic purposes
Hardware Specifications:
- Dimensions: Standard 1769 single-slot module
- Current Load: 800 mA max @ 5 VDC
- Operating Temp: 32°F to 140°F (0°C to 60°C)
- Storage Temp: -40°F to 185°F (-40°C to 85°C)
- Relative Humidity: 5% to 95% (no condensation)
- LED Indicators: Battery and Module Status, Application Status, Serial Port Activity, CFG Port Activity
- CFG Port: RS-232 only, no hardware handshaking
- App Ports (P1, P2): RS-232, RS-485, or RS-422 (jumper selectable), RS-232 handshaking configurable, 500V Optical isolation from backplane
- Shipped with Unit: RJ45 to DB-9M cables for each port, 6-foot RS-232 configuration cable
