Description
The ICS T8220 is a high-reliability dual AC input power supply module designed for use in Trusted® and ICS safety and control systems. It converts a wide-range AC input into a regulated +15 VDC output, providing stable and continuous power to processor, I/O, and communication modules within the system chassis.
Featuring dual AC inputs, the T8220 supports redundant power source configurations, enhancing system availability and ensuring uninterrupted operation in critical industrial applications. The module is engineered for high power factor and robust immunity to electrical noise, surges, and transients, making it suitable for harsh industrial environments. Internal protection features, comprehensive EMI compliance, and safety certifications further ensure dependable long-term performance. The T8220 supports both natural convection and forced-air cooling, allowing flexible installation across a wide range of operating conditions.
Specifications
| Parameter | Specification |
|---|---|
| Input Voltage Range | 85 to 264 VAC |
| Input Frequency Range | 47 to 63 Hz |
| Inrush Current (120 / 260 VAC) | 20 / 40 A (peak) cold, 35 / 65 A (peak) hot |
| Power Factor | ≥ 0.95 |
| Efficiency | 70% |
| Internal Fusing | 6 A, 250 V, 3AG slow-blow |
| Output Voltage | +15 VDC |
| Output Power | 250 W per module |
| Power Hold-up Time | ≥ 20 ms |
| Operating Temperature | |
| Natural Convection | −20 °C to +50 °C |
| Forced Air (>20 lf/min) | −20 °C to +70 °C |
| Storage Temperature | −40 °C to +85 °C (−40 °F to +185 °F) |
| Operating Humidity | 0 to 95% RH, non-condensing |
| Vibration | 10 to 55 Hz, ±0.15 mm |
| Shock (Operating) | 15 g, ½ sine wave, 11 ms |
| Electromagnetic Immunity | IEC 801-2 (ESD), IEC 801-3 (Radiated EMI), IEC 801-4 (Transients/Bursts), IEC 801-5 (Surge), ANSI/IEEE C37.90 |
| ESD Immunity | Level 3, 6 kV contact discharge |
| Radiated Field Immunity | Level 3, 10 V/m, 27–500 MHz |
| Fast Transients/Bursts | Level 4, 2 kV, 2.5 kHz for 60 s |
| Surge Immunity | Level 3, 2 kV; 2.5 kV damped 1 MHz sine wave |
| Impulse Withstand | 4 kV bi-directional impulse, 10 ns rise time |
| Safety Certification | DIN V VDE 0801 (Risk Class 5); designed to meet UL 508 and CSA 22.2 No. 142-M1981 |
| Module Dimensions (H × W × D) | 266 × 61 × 318 mm (10.47 × 2.38 × 12.5 in) |
| Chassis Dimensions (H × W × D) | 266 × 483 × 343 mm (10.47 × 19 × 13.5 in) |
| Module Weight | 3.2 kg (6.9 lb) |
