Honeywell EPDGP I/O Board 51304584-100

Product Overview

The Honeywell 51304584-100 is an EPDGP I/O Board for the Universal Station. It provides interfaces for video, cursor control, keyboard, Zip/Bernoulli drive, and printer connections.

Technical Specs

• Type: EPDGP I/O Board
• System: Honeywell Universal Station (TDC 3000)
• Interfaces: Video, keyboard, cursor, drive, printer
• Revision note: Rev G or higher required for Bernoulli/Zip drives
• Compatibility: Not for single-cable keyboard interfaces (use -200/-300)

Key Features

• Central peripheral interface for Universal Station
• Supports multiple station peripherals
• Designed for reliable operator station operation
• Field-proven in TDC environments

FAQ

• What does it connect? Video, keyboard, cursor, drive, and printer.
• Drive support? Rev G or above for Bernoulli/Zip.
• Keyboard note? Not compatible with single-cable keyboard interfaces.

Installation Guide

1. Power down the Universal Station.
2. Install the EPDGP I/O board in the designated position.
3. Connect video, keyboard, cursor, and peripheral cables.
4. Restore power and verify all peripheral functions.
5. Test display, keyboard, and drive operation.

Selection Tips

• Confirm keyboard interface type before ordering.
• Use Rev G or higher if Bernoulli or Zip drives are present.
• Essential spare for Universal Station maintenance.
