Description
The Digital Output Module – DC Type (900H02-0001) provides 16 outputs, separated into 2 groups of 8 channels each, which are externally powered. Each group has a pair of screw terminals for +V and COM connections.
The outputs are low side switching (current sinking) type. Overload protection is built into each output; when tripped, power must be recycled to reset the module.
Technical Specifications
| Parameter | Specification |
|---|---|
| Outputs per module | 16 (current sinking, low side) |
| Galvanic Isolation | 2 groups of 8 outputs |
| Operating Voltage | 6.5 to 32 VDC (5.0 to 6.5 V @ <0.5A per channel) |
| Output Type | Intelligent power switch (IPS) |
| Peak Voltage | 34 VDC |
| AC Frequency | N/A |
| ON Voltage Drop | 0.3VDC @ 1 A load |
| Overload Protection | Electronic high current and high temperature limiting, resets after cycling field power |
| Maximum Load Current | 1 A per point, 8A max. per module, resistive load 0.5 A per point incandescent lamp load (5 mH max) |
| Maximum Leakage Current | 0.15mA @ 32 VDC |
| Maximum Inrush Current | 4 A for 10 ms |
| Minimum Load | 0.0 mA |
| OFF to ON response time | 6 ms |
| ON to OFF response time | 6 ms |
| Fuses | Electronic limiting |
| Power Supply Loading | 5V; 340mA 24V; 0mA |
