Honeywell 8C-PDIL51 51454359-175 Digital Input Module

Product Description

The Honeywell 8C-PDIL51 is a digital input module designed for industrial automation applications. It provides 8 isolated digital inputs, capable of accepting 24VDC signals, ensuring reliable data acquisition for process control systems. This module integrates seamlessly with Honeywell’s Universal Process Controller (UPC), Experion PKS, and TDC 3000.

Technical Parameters

• Input Channels: 8 isolated digital inputs

• Signal Type: 24VDC

• Compatibility: Universal Process Controller (UPC), Experion PKS, TDC 3000

• Operating Temperature: -40°C to 70°C

• Dimensions:

• Net Depth/Length: 100 mm

• Net Height: 150 mm

• Net Width: 50 mm

• Net Weight: 0.5 kg

• Protection Rating: IP20

• Isolation: 1000 VAC RMS for system-to-field isolation (with user-supplied field power)

• Input Impedance: 4.2 kΩ

• ON Sense Voltage/Current: 13 VDC (min) or 3 mA (min)

• OFF Sense Voltage/Current: 5 VDC (max) or 1.2 mA (max)

• Absolute Delay Across Input Filter and Isolation: 5 ms ± 20%
