Honeywell 51405043-175 CC-PDOB01 32pt 24VDC Digital Output Module

Product Overview

The Honeywell 51405043-175 is the assembly number for the CC-PDOB01 32-point 24 VDC Digital Output module used in Experion PKS and related Series C / Chassis I/O platforms. It provides solid-state DC outputs for controlling field devices such as solenoids, relays and indicators.

Technical Specs

• Hardware model: CC-PDOB01
• Assembly number: 51405043-175
• Channels: 32 digital outputs
• Output type: Solid-state DC (sourcing/sinking configurable)
• Load voltage: 24 VDC class (up to 30 VDC max typical)
• Current: Typically 0.5 A per channel class with individual fusing
• Isolation: Channel-group isolation
• Hot-swap: Supported in compatible systems
• System: Experion PKS / Series C I/O

Key Features

• High-density 32-point digital outputs
• Configurable sourcing or sinking logic
• Per-channel diagnostics and fusing
• Hot-swappable in supported chassis

FAQ

• Channels? 32.
• Voltage? 24 VDC class.
• Model? CC-PDOB01 (51405043-175).

Installation Guide

1. Install the module in the Experion Series C or compatible I/O chassis.
2. Configure channel polarity (source/sink) as required.
3. Wire field loads observing current and voltage limits.
4. Power up and verify channel status LEDs and diagnostics.
5. Test each output under load.

Selection Tips

• Ideal for high-density 24 VDC discrete output applications.
• Confirm chassis and firmware compatibility.
• Keep as spare for Experion digital output racks.
