GE IS200ICIAH1AAB Innovation I/O Board
GE IS200ICIAH1AAB Innovation I/O Board
Manufacturer: GE
Product No.: IS200ICIAH1AAB
Product Type: Innovation I/O Board
Product Origin: USA
Payment: T/T
Weight: 400g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The IS200ICIAH1AAB Innovation I/O Board is part of the GE Mark VI series and is primarily used for interfacing 32 isolated digital input points grouped into 8 sets, translating real-world field signals into conditioned signals for the turbine control processor. The board’s design includes optical isolation for enhanced noise immunity, status LEDs for visual diagnostics at each channel, and a rack-mount modular PCB form factor that simplifies installation and maintenance. Its high-density input architecture allows for compact yet robust signal acquisition in harsh industrial conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model / Part Number | IS200ICIAH1AAB |
| Product Type | Innovation I/O Interface Board |
| System Compatibility | GE Mark VI Speedtronic turbine control system |
| Digital Input Channels | 32 inputs (grouped into 8 sets) |
| Recommended Input Voltage Range | 20–42.5 V DC |
| Maximum Input Voltage | 42.5 V DC |
| Switching Thresholds | Off→On: ~10 V DC typical (12 V worst case); On→Off: ~5 V DC typical (4 V worst case) |
| Input Current | 3–5 mA nominal |
| Input Impedance | >1.25 kΩ |
| Input Delay | Off→On <8 ms; On→Off <15 ms |
| Isolation | Optical isolation ≥1000 VAC / 1500 V DC per point |
| LED Indicators | Per-channel status LEDs; module health LED |
| Power Consumption | <10 W typical; 0.5–1.5 W per channel depending on voltage |
| Board Dimensions | 4 × 18.6 × 26.1 cm |
| Weight | 0.4 kg |
| Mounting | Rack-mounted, plug-in module |
| Operating Temperature | –40 °C to +70 °C (typical industrial range) |
| Country of Origin | USA (common for this series) |
| Warranty | Typical 12 months (depends on supplier) |
