Description
The IC695MDL765 is a smart discrete DC voltage output module designed for the RX3i PACSystems platform. It provides high-current, fast-response transistor outputs suitable for demanding industrial automation and control applications, such as actuators, solenoids, relays, and indicator devices.
With built-in diagnostics and protection features, the module ensures reliable operation and early fault detection. It supports wide DC voltage ranges, occupies a single slot on the Universal Backplane, and communicates via the PCI bus, making it well suited for high-performance and mission-critical control systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | RX3i DC Voltage Output Module, 24/125 VDC, 2 A Smart Digital Output, 16-Point Output |
| Lifecycle Status | Active |
| Module Type | Discrete Output |
| Backplane Support | Universal Backplane Only; Uses PCI Bus |
| Number of Backplane Slots | 1 |
| Output Voltage Range | 18 to 30 VDC; 105 to 132 VDC |
| Number of Points | 16 |
| Isolation | N/A |
| Diagnostics | Output Pulse Test; Over-Temperature; Failed Switch Detection; Overload Detection and Shutdown; No-Load Detection |
| Load Current per Point | 2 A |
| Response Time | 1 ms maximum |
| Output Type | Transistor |
| Polarity | Positive |
| Points per Common | 16 |
| Connector Type | IC694TBBx32 or IC694TBSx32 (Sold Separately) |
| Internal Power Consumption | 540 mA @ 5.1 VDC; 152 mA @ 3.3 VDC |
