Foxboro A2H124-48 Layer 2 Managed Ethernet Switch

Product Overview

• Industrial-grade Layer 2 managed Ethernet switch

• Designed for high-density networking in automation, transportation, and utility systems

• Supports stacking up to 8 units for scalable deployment

• Optional PoE+ support for powering IP devices

• Origin: USA

• Warranty: 12 months

• Mounting: DIN rail or 1U rack-mountable

• IP Rating: IP30 standard, IP67 ruggedized variant

Technical Specifications

• Port Configuration:

• 48 × 10/100Base-TX RJ-45 copper ports

• 2 × 10/100/1000Base-T RJ-45 uplink/stacking ports

• 2 × Gigabit SFP uplink ports

• 1 × RS-232 DB9 console port

• Performance:

• Switching capacity: 17.6 Gbps (standalone), 140.8 Gbps (stacked)

• Forwarding rate: 13.1 Mpps (standalone), 104.8 Mpps (stacked)

• MAC address table: 16,000 entries

• Jumbo frame support: up to 9216 bytes

• Power & Consumption:

• Input voltage: 100–240V AC, 50–60 Hz

• Power consumption: 30–150 W (depending on PoE usage)

• Dual power input support for redundancy

• Environmental Conditions:

• Operating temperature: -40°C to +75°C

• Humidity: 5% to 95%, non-condensing

• Fanless design for enhanced reliability

• Physical Dimensions:

• Width: 44.1 cm

• Height: 4.4 cm

• Depth: 21.0 cm

• Weight: 2.7–4.7 kg (varies by model variant)
