Description
TDISecure with DC power input (Model: 2155/40-02) is an industrial-grade data acquisition unit that provides 24 channels of configurable direct analog inputs. It is engineered to interface with various signal types such as 4–20 mA current loops and voltage ranges from 0–10 V, enabling precise signal capture in process control and monitoring environments. The device operates efficiently on a DC power supply between 20–36 VDC and is optimized for both accuracy and durability in extended operating conditions. Its compact form factor and wide environmental tolerance make it well-suited for fixed installations in harsh industrial settings.
Specifications
-
DC Input: 20–36 VDC, 35 W
-
Direct Analog Inputs
-
0.32% FS at 25 °C (10 V full scale)
-
0.64% FS at 25 °C (4–20 mA)
-
Supports 2 groups of 12 channels (24 total), differential type
-
Each group configurable for: 4–20 mA, 1–5 V, 0–5 V, 0–10 V, or 2–10 V
-
4–20 mA input impedance: 250 Ω
-
Voltage mode input impedance: 400 kΩ
-
Frequency response: DC to 240 Hz @ −3 dB
-
Scan rate: 400 ms for all 24 channels
-
Accuracy:
Environmental Limits
-
Operating Temperature: −30 °C to +65 °C (−22 °F to +149 °F)
-
Storage Temperature: −40 °C to +85 °C (−40 °F to +185 °F)
-
Humidity: Max 95%, non-condensing
-
Pollution Degree: 2
-
Installation Category: II, for indoor use
-
Altitude: Up to 2000 m
-
Battery Life:
-
Powered TDISecure: 115 years @ 25 °C (77 °F)
-
Un-powered TDISecure: 19 years @ 25 °C (77 °F)
Physical
-
Dimensions (W × D × H): 384 mm (15.12 in) × 216 mm (8.50 in) × 136 mm (5.36 in)
-
Weight: 3.9 kg (8.6 lb)
