Bently Nevada 3500/05 138945-01 Standard Backplane

Product Description

The Bently Nevada 3500/05 138945-01 Standard Backplane is a fundamental component of the 3500 Machinery Protection System. It serves as the physical and electrical foundation for the 3500 rack, accommodating various modules that perform machinery monitoring and protection functions. This backplane facilitates communication and power distribution between the modules, ensuring reliable and efficient system operation. It is designed to meet the rigorous demands of industrial environments, providing a robust and dependable platform for critical machinery protection.

Technical Specifications

• Model Number: 3500/05

• Part Number: 138945-01

• Type: Standard Backplane

• Compatibility: Bently Nevada 3500 Series Modules

• Power: Distributes power from the rack power supplies to the modules.

• Communication: Facilitates communication between modules via the rack's internal communication bus.

• Mounting: Designed for rack mounting within a 3500 rack enclosure.

• Environmental: Designed to operate within standard industrial environmental conditions.

• Size: Standard 19 inch rack size.

• Connectors: Connectors to accept 3500 modules.

• LED Indicators: Some backplanes may have led indicators for power and communication status.
