ABB IMHSS03 Hydraulic Servo Module
ABB IMHSS03 Hydraulic Servo Module
Manufacturer: ABB
Product No.: IMHSS03
Product Type: Hydraulic Servo Module
Product Origin: Switzerland
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Description
-
Harmony rack I/O incorporates a variety of input and output devices to interface process signals to the Symphony™ Enterprise Management and Control System.
-
An IMHSS03 Hydraulic Servo module and an IMFCS01 Frequency Counter module interface field inputs and outputs used in turbine control.
-
The modules each consist of a single printed circuit board that occupies one slot in a module mounting unit (MMU).
-
Configuration:
-
Jumpers and switches on the printed circuit board
-
Jumpers and dipshunts on the termination unit
-
A cable connects the I/O module to its termination unit.
-
The physical connection points for field wiring are on the termination unit.
Specifications
| Property | Characteristic/Value |
|---|---|
| General | |
| Mounting | Occupies one slot in a standard module mounting unit. |
| Environmental | |
| Ambient temperature | 0° to 70°C (32° to 158°F) |
| Relative humidity | 5% to 95% up to 55°C (131°F) (noncondensing) 5% to 45% at 70°C (158°F) (noncondensing) |
| Altitude | Sea level to 3 km (1.86 miles) |
| Air quality | Noncorrosive |
| Surge protection | Meets IEEE-472-1974 surge withstand capability test. |
| CE mark declaration (pending for IMFCS01) | |
| EMC96 Directive 89/336/EEC | EN50082-2 Generic Immunity Standard - Part 2: Industrial Environment EN50081-2 Generic Emission Standard - Part 2: Industrial Environment |
| Low Voltage Directive 73/23/EEC | EN61010-1 Safety Requirements for Electrical Equipment for Measurement, Control and Laboratory Use - Part 1: General Requirements |
| Certifications | |
| Canadian Standards Association (CSA) | Certified for use as process control equipment in an ordinary (nonhazardous) location. |
| Factory Mutual (FM) (pending for IMHSS03) | Approval for the following categories: - Nonincendive for: * Class I Division 2, Groups A, B, C, D * Class II, Division 2, Groups F, G |
| IMHSS03 | |
| Power requirements | |
| Operating voltage | +5 VDC, ±5% at 576 mA typical +15 VDC, ±5% at 15 mA typical -15 VDC, ±5% at 12 mA typical +24 VDC, ±10% at 335 mA typical (from termination unit) |
| Power dissipation | |
| +5 VDC | 2.88 W typical |
| +15 VDC | 0.23 W typical |
| -15 VDC | 0.18 W typical |
| +24 VDC | 8.04 W typical |
