ABB G4AA HENF209644R5 Control Board
ABB G4AA HENF209644R5 Control Board
Manufacturer: ABB
Product No.: G4AA HENF209644R5
Product Type: Control Board
Product Origin: USA
Payment: T/T
Weight: 750g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The ABB G4AA HENF209644R5 is a specialized control board intended for integration into the ABB ETL600 Digital Power Line Carrier System (Release 1.0). This board combines a DPLC (Digital Power Line Carrier) modem module, digital signal processing capabilities, and a human-machine interface (HMI) interface into one unit. Its role is to convert low-frequency (LF) signals to radio-frequency (RF), perform real-time signal processing, and manage communication over power line carrier channels. It includes multiple communication ports and status LEDs to support diagnostics, monitoring, configuration, and alarm signaling in power transmission and utility applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | G4AA HENF209644R5 |
| Product Type | Control Board |
| System Compatibility | ABB ETL600 Digital Power Line Carrier System (Release 1.0) |
| Core Function | LF↔RF signal conversion, digital signal processing, modem interface |
| Data Transmission Rate | 50 to 9,600 bps (narrowband) |
| Voltage / Signal Inputs | 1 × V.11, 2 × V.24 |
| Communication Interfaces | 4 × RS-232 (V.24/V), 1 × Sub-D 15-pin (V.11), 1 × Sub-D 9-pin (HMI), IRIG-B port |
| LED Indicators | RDY (green, system ready), P4LT (red, hardware alarm), SYS (red, system alarm) |
| Connectors & Mounting | DIN 41612 header, screw terminals, quick-connect plugs |
| Operating Temperature | –20 °C to +70 °C |
| Humidity | Up to 95%, non-condensing |
| Dimensions (L × W × H) | 132 mm × 53 mm × 65 mm |
| Weight | 0.75 kg |
| Country of Origin | Sweden / Switzerland |
| Warranty | 12 months |
