ABB DI630 Digital Input Module
ABB DI630 Digital Input Module
Manufacturer: ABB
Product No.: DI630
Product Type: Digital Input Module
Product Origin: USA
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Decription
The ABB DI630 Digital Input Module is a robust and high-performance input unit designed for ABB control and protection systems, enabling reliable acquisition of digital field signals such as limit switches, push buttons, proximity sensors, and relay contacts. Featuring multiple isolated input channels, the module ensures stable signal processing, strong noise immunity, and fast response times in harsh industrial environments. Its compact form factor allows seamless integration into ABB automation platforms for process control, power generation, and manufacturing applications.
Technical Specifications
| Parameter | Description |
|---|---|
| Number of Inputs | 16 digital input channels |
| Input Signal Type | 24 V DC (positive logic) |
| Rated Input Voltage | 24 V DC |
| Operating Voltage Range | 18 – 30 V DC |
| Input Current per Channel | Approx. 6 mA at 24 V DC |
| Input Threshold (ON) | ≥ 15 V DC |
| Input Threshold (OFF) | ≤ 5 V DC |
| Electrical Isolation | Channel-to-system isolated |
| Response Time | ≤ 5 ms |
| Input Protection | Reverse polarity and surge protected |
| Status Indication | Individual LED per channel |
| Power Consumption | Approx. 3 W |
| Mounting Type | Rack or DIN rail (system dependent) |
| Operating Temperature | –25 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Protection Rating | IP20 |
| Typical Applications | Sensors, switches, contact monitoring |
