ABB DC562 1SAP231900R0000 Digital Input/Output Module

General Information

• Extended Product Type: DC562

• Product ID: 1SAP231900R0000

• ABB Type Designation: DC562

• EAN: 4016779927574

• Catalog Description: Digital input/output module. Transistor: 16DC: 0.5 A (DC562)

• Long Description: DC562: S500-eCo Digital input/output module. 16 configurable DI/DO: 24VDC 0.5A. 1-wire

Dimensions

• Product Net Weight: 0.15 kg

• Product Net Depth / Length: 75 mm

• Product Net Height: 135 mm

• Product Net Width: 34 mm

• Gross Weight: 0.222 kg

• Package Level 1 Depth / Length: 93 mm

• Package Level 1 Height: 63 mm

• Package Level 1 Width: 170 mm

• Package Level 1 Units: 1 carton

Certificates and Declarations

• Declaration of Conformity - CE: S500-eCo EU DoC

• REACH Date: 2024-12-06

• REACH Declaration: REACH declaration ABB PLC products

• REACH Information: Contains substances > 0.1 mass percentage

• RoHS Date: 2013

• RoHS Information: S500-eCo EU DoC

• RoHS Status: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Technical Details

• Function: 16 configurable DI/DO: 24VDC 0.5A

• Number of Digital Configurable I/Os: 16

• Input Voltage Type: DC

• Input Current: 5 mA

• Maximum Input Voltage: 0 ... 30 V

• Delay Time (τ): 8 … 8 ms

• Output: Transistor

• Output Voltage Type: DC

• Output Current: 0.5 A

• Output Voltage Maximum: 20.4 … 28.8 V

• Connection Type: Pluggable

• Degree of Protection: IP20

• Supply Voltage: 20.4 … 28.8 V DC
