ABB CBI 20 - Binary Input Module
ABB CBI 20 - Binary Input Module
Manufacturer: ABB
Product No.: CBI 20
Product Type: Binary Input Module
Product Origin: USA
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Description
The ABB CBI 20 is a high-performance binary input module designed for industrial automation applications. It features 32 binary inputs, divided into two supply groups of 16 inputs each, ensuring efficient signal processing and separation.
• High-resolution signal recording with 1 ms time accuracy, allowing precise event detection
• Galvanic isolation for secure system integration and signal separation
• Integrated module monitoring for enhanced diagnostics and reliability
• Configurable group-set filter time, optimizing input signal processing
• Redundancy support, ensuring operational reliability in critical systems
Technical data
| Parameter | Value |
|---|---|
| Supply voltage | UVS = 43 ... 50 V (48 V typ.) for external powering of up to 60 V |
| Input resistance | RE = 15.9 kΩ |
| Input rated current | IRated = 3 mA |
| Signal input level | UeHigh = 36 ... 60 V |
| With contact switching (non-redundant) | UeLow = 9.1 ... 15.2 V |
| With contact switching (redundant) | UeLow = 5.2 ... 8.7 V |
| High / Low - threshold | UH/L = 21 V |
Table: Contact Interrogation (24 V)
| Parameter | Value |
|---|---|
| Supply voltage | UVS = 20.4 ... 28.8 V (24 V typ.) |
| Input resistance | RE = 5.8 kΩ |
| Input rated current | IRated = 4.2 mA |
| Signal input level | UeHigh = 20.4 ... 28.8 V |
| With contact switching (non-redundant) | UeLow = 3.9 ... 5 V |
| With contact switching (redundant) | UeLow = 2.1 ... 2.7 V |
| High / Low - threshold | UH/L = 8.4 V |
