Product Description
The ABB Bailey IMSET01 is a Sequence of Events Timing Module designed for ABB's Symphony control system. This module is used to monitor and record time-stamped events with high accuracy, aiding in troubleshooting and system diagnostics. It provides precise event logging and synchronization with the overall control system, making it a crucial component in industrial automation applications.
Technical Specifications
-
Model Number: IMSET01
-
Function: Sequence of events (SOE) monitoring and timing
-
System Compatibility: ABB Symphony control system
-
Timestamp Resolution: 1 millisecond (ms)
-
Input Signal Type: Digital event inputs
-
Number of Inputs: 16 channels
-
Time Synchronization: Supports GPS or system-wide synchronization
-
Communication Protocol: Proprietary ABB Bailey communication protocol
-
Power Supply:
-
Operating Voltage: 24V DC
-
Power Consumption: <10W
-
Operating Temperature: 0°C to +60°C
-
Storage Temperature: -40°C to +85°C
-
Mounting: Rack-mounted
-
Weight: Approximately 500g
