3300 XL 8 mm Proximity Transducer System

Description

• Consists of:

• One 3300 XL 8 mm probe

• One 3300 XL extension cable¹

• One 3300 XL Proximitor Sensor²

• Provides an output voltage directly proportional to the distance between the probe tip and the observed conductive surface.

• Measures both static (position) and dynamic (vibration) values.

• Primary applications:

• Vibration and position measurements on fluid-film bearing machines

• Keyphasor reference and speed measurements³

• Delivers advanced performance in eddy current proximity transducer systems.

• The standard 3300 XL 8 mm 5-meter system fully complies with API 670 standards for:

• Mechanical configuration

• Linear range

• Accuracy

• Temperature stability

• Provides complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need for matching or bench calibration.

• Each component is backward compatible and interchangeable⁴ with non-XL 3300 series 5 mm and 8 mm transducer system components⁵.

• Compatibility includes the 3300 5 mm probe, suitable for applications where an 8 mm probe is too large for the available mounting space⁶,⁷.
