HIMA F-7531 Printed Circuit Board (PC Board) Module
HIMA F-7531 Printed Circuit Board (PC Board) Module
Manufacturer: HIMA
Product No.: F-7531
Product Type: Printed Circuit Board (PC board) Module
Product Origin: Germany
Payment: T/T
Weight: 400g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The HIMA F-7531 is a printed circuit board (PC board) module designed for use within HIMA safety-related programmable electronic systems (PES).
It functions as a two-fold relay amplifier, enabling the amplification and switching of control signals for safety-critical applications.
Each channel is independently monitored, providing high reliability for industrial process automation, petrochemical plants, and energy systems.
The module is intended for installation in standard rack systems and integrates seamlessly with other HIMA components.
Technical Data
| Parameter | Specification |
|---|---|
| Model / Part Number | F-7531 / 981753102 |
| Function | Two-fold relay amplifier module |
| Number of Safety Channels | 8 independently monitored channels |
| Input Power / Supply Voltage | 48/60 VDC or 60 VAC; also supports 24 VDC ±15% |
| Contact Rating | 5 A at 230 VAC per channel |
| Response Time | ≤ 10 ms per channel |
| Isolation | Optical and galvanic isolation between channels |
| Crosstalk Between Channels | < 0.1% |
| Operating Temperature | −20 °C to +60 °C |
| Humidity | Up to 95% relative humidity, non-condensing |
| Dimensions (H × W × D) | 45 × 121 × 114 mm |
| Weight | 0.4 kg |
| Mounting | 19-inch, 5-unit high central rack |
