FOXBORO FBM217 P0914TR Discrete Input Interface Module
FOXBORO FBM217 P0914TR Discrete Input Interface Module
Manufacturer: FOXBORO
Product No.: FBM217 P0914TR
Product Type: Input Interface Module
Product Origin: USA
Payment: T/T
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The FBM217 is a Discrete Input Interface Module from the Foxboro I/A Series of distributed control system (DCS) components. It provides 32 isolated discrete input channels designed to interface field sensor signals (e.g., switch status, contact closures, and logic signals) with the control system. Each channel accepts two-wire DC voltage inputs, with the module performing signal conditioning and isolation to ensure reliable, noise-immune signal transmission into the DCS. The FBM217 is engineered for industrial environments and supports installation in redundant configurations for higher availability systems. LEDs on the front panel provide status indication for module operation and channel states, and the module communicates with its associated Fieldbus interface for robust integration into Foxboro control architectures.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model / Part Number | FBM217 P0914TR |
| Product Type | Discrete Input Interface Module |
| Manufacturer | Foxboro (Schneider Electric) |
| Input Channels | 32 isolated input channels |
| On-State Voltage (Input) | 15 to 30 V DC |
| Off-State Voltage (Input) | 0 to 5 V DC |
| Input Current | Typically 2.2 mA at 30 V DC |
| Source Resistance Limits | On-state ≤ 1 kΩ @ 15 V DC; Off-state ≥ 100 kΩ @ 30 V DC |
| Filter / Debounce Time | Configurable: No filtering, 4, 8, 16, or 32 ms |
| Maximum Pulse Count Rate | 250 Hz |
| Communication Interface | Redundant 2 Mbps Module Fieldbus via FCM or FCP |
| Power Requirements | 24 V DC ±5%, -10% (redundant support) |
| Power Consumption | ≤ 3 W at 24 V DC |
| Heat Dissipation | ≤ 5 W at 24 V DC |
| Operating Temperature | -20 °C to +70 °C (-4 °F to +158 °F) |
| Relative Humidity | 5 % to 95 % (non-condensing) |
| Altitude Range | -300 m to +3000 m (-1000 ft to +10 000 ft) |
| Mounting | Module mounts on a Foxboro baseplate (DIN rail or rack) |
| Weight | 284 g (module only) |
| Dimensions (H × W × D) | 102 mm × 45 mm × 104 mm (with mounting lugs) |
| Environmental Rating | Class G3 (Harsh) industrial environments |
| Warranty | Typically 12 months (industry standard) |
| Country of Origin | USA |
