BENTLY NEVADA 330901-00-41-05-02-CN NSv Proximity Probe
BENTLY NEVADA 330901-00-41-05-02-CN NSv Proximity Probe
Manufacturer: Bently Nevada
Product No.: 330901-00-41-05-02-CN
Product Type: Proximity Probe
Product Origin: USA
Payment: T/T
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Description
BENTLY NEVADA 330901-00-41-05-02-CN is an NSv eddy-current proximity probe designed for non-contact measurement of shaft vibration and position in rotating machinery. It is part of the Bently Nevada 3300 NSv Proximity Transducer System, widely used in machinery protection and condition monitoring applications.
The probe delivers stable and accurate displacement signals when used with the corresponding NSv Proximitor® sensor and extension cable. Its compact probe body and miniature coaxial ClickLoc connector make it suitable for installations with limited space, while maintaining high reliability in demanding industrial environments. The CN suffix indicates a version configured for the China market, without affecting electrical performance or compatibility.
Part Number Breakdown: 330901-AA-BB-CC-DD-EE
| Segment | Code | Description |
|---|---|---|
| A: Unthreaded Length Option | 00 | 0 in |
| B: Overall Case Length Option | 41 | 4.1 in |
| C: Total Cable Length Option | 05 | 0.5 meter (20 in) |
| D: Connector and Cable-Type Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| EE: Market Version | CN | China Market Version |
Typical Characteristics (NSv Proximity Probe Family)
| Parameter | Specification |
|---|---|
| Probe Type | Eddy-current proximity probe |
| Measurement Function | Shaft vibration and displacement |
| Probe Tip Diameter | 8 mm |
| Nominal Measurement Range | 2.0 mm (80 mils) |
| Linear Range | 1.6 mm (63 mils) |
| Scale Factor | 7.87 V/mm (200 mV/mil) |
| Frequency Response | 0 to 10 kHz |
| Operating Temperature | −51 °C to +177 °C |
| Connector Type | Miniature coaxial ClickLoc |
| Compatible Systems | Bently Nevada 3300 NSv Proximity Transducer System |
