ABB 5SHX14H4502 Symmetric Integrated Gate-Commutated Thyristor (IGCT)

ABB 5SHX14H4502 Symmetric Integrated Gate-Commutated Thyristor (IGCT)

  • Manufacturer: ABB

  • Product No.: 5SHX14H4502

  • Product Type: IGCT

  • Product Origin: Switzerland

  • Payment: T/T

  • Weight: 0g

  • Shipping port: Xiamen

  • Warranty: 12 months

General Information

  • Product Type: Symmetric Integrated Gate-Commutated Thyristor (IGCT)

  • Manufacturer: ABB

  • Product ID: 5SHX14H4502

  • ABB Type Designation: IGCT Power Semiconductor

  • Application: Designed for high-power converter and drive systems, providing fast switching capability and superior thermal performance.

  • Function: Acts as a controllable switch for converting and controlling large electric power levels efficiently in industrial and traction systems.

  • Features: High reliability, low on-state voltage drop, robust surge current handling, and long service life.

Technical Specifications

  • Device Type: Symmetric IGCT

  • Repetitive Peak Off-State Voltage (V<sub>DRM</sub> / V<sub>RRM</sub>): 4500 V

  • On-State Current (I<sub>T(AV)</sub>): 1400 A (average)

  • Peak On-State Current (I<sub>TSM</sub>): 40 kA

  • Turn-off Time (t<sub>q</sub>): Typically < 100 µs

  • Operating Junction Temperature (T<sub>vj</sub>): -40 °C to +125 °C

  • Mounting Type: Press-pack device

  • Cooling Method: Conduction or forced air cooling through heat sink

  • Package Form: Disc-type ceramic housing with metal terminals

  • Typical Applications:

    • Medium-voltage drives

    • Static VAR compensators

    • Industrial frequency converters

    • Power grid converters
