BENTLY NEVADA 121M6466 Wireless Triaxial Vibration & Temperature Sensor
BENTLY NEVADA 121M6466 Wireless Triaxial Vibration & Temperature Sensor
Manufacturer: Bently Nevada
Product No.: 121M6466
Product Type: Sensor
Product Origin: USA
Payment: T/T
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
Product Description
-
The 121M6466 is a wireless triaxial vibration and temperature sensor, part of the Ranger Pro series, designed for continuous condition monitoring of rotating machines in industrial and hazardous environments.
-
It provides vibration data along three axes (X, Y, Z) plus integrated temperature measurement, allowing diagnostic insight including overall values, spectral and demodulation analyses.
-
Communication uses the ISA100.11a wireless protocol (or in some variants, WirelessHART) for robust, encrypted data transmission in operating plants.
-
The device supports over-the-air configuration, lives up to extended battery life, and integrates with condition monitoring systems (e.g. System 1) through gateways.
-
Its rugged construction, sealing, and certifications suit use in harsh and explosive atmospheres.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 121M6466 |
| Sensor Type | Wireless triaxial accelerometer + temperature |
| Amplitude Range (Acceleration) | ±20 g peak (0 to 200 m/s²) |
| Measurement Accuracy | ±5 % (Z axis at 160 Hz) ; ±10 % (X / Y axes at 160 Hz) |
| Transverse Sensitivity (typical) | ~7 % |
| Acceleration Frequency Range | Z axis: 5 Hz to 10 kHz (±3 dB) ; X / Y axes: 5 Hz to 4 kHz (±3 dB) |
| Selectable Filter Cutoffs | Fmin options: 2, 5, 10, 100, 200 Hz Fmax options: 200, 500, 1,000, 2,000, 5,000, and for Z axis up to 10,000 Hz |
| Sample Points (per waveform) | 1,024 ; 2,048 ; 4,096 ; 8,192 |
| Velocity Measurement | Frequency range 5 Hz to 2,000 Hz; amplitude range 0 – 50 mm/s |
| Peak Demodulation | Z-axis demod spectrum; configurable bandwidths and intervals |
| Temperature Range | Integrated sensor: –40 °C to +120 °C |
| Resolution (Temperature) | 0.1 °C |
| Wireless Protocol | ISA100.11a (or WirelessHART in some variants) |
| Radio Frequency | 2.45 GHz ISM band, IEEE 802.15.4 |
| Wireless Output Power | Up to 10 mW |
| Transmission Range | Up to ~150 m sensor to access point (line of sight) |
| Encryption / Security | 128-bit AES |
| Mounting | Internal thread M6 × 1 (depth ~5 mm) |
| Physical & Mechanical | Height: ~88 mm ; Diameter: ~40 mm ; Weight: ~230 g (without battery), ~300 g (with battery) |
