ABB IM/C1900-OGR Operating Guide Recorder

Product Description

The ABB IM/C1900-OGR is a C1900 Series Circular Chart Recorder, specially designated as an Operating Guide Recorder. It is designed to continuously record one or two process variables—such as temperature, pressure, or flow rate—on a 10-inch circular chart, providing a clear, analog representation of process behavior over time. The OGR version includes enhanced guidance features for operator reference, such as preset alarm thresholds and operator instructions on the chart, making it ideal for critical or regulated processes.

Technical Specifications

• Model Number: IM/C1900-OGR

• Recorder Type: Operating Guide Recorder (Circular Chart)

• Chart Diameter: 10 inches (250 mm)

• Number of Pens: 1 or 2-channel recording

• Chart Speed Options:

• Configurable from 1 hour to 7 days per revolution

• Supports multiple chart speed settings

• Input Signal Types:

• Thermocouples: Types J, K, T, R, S, etc.

• RTDs: Pt100 (3-wire)

• Analog Signals: 4–20 mA, 0–10 V, 1–5 V, mV

• Measurement Accuracy: ±0.25% of span (typical)

• Recording Mechanism:

• Electromechanical pen & ink system

• Precision chart tracing with manual or motor-driven movement

• Power Supply:

• 90–264 V AC, 50/60 Hz

• Optional: 24 V DC models available

• Alarm Capabilities:

• Optional relay outputs for high/low alarms

• Adjustable alarm setpoints based on guide marks on chart

• Environmental Conditions:

• Operating Temperature: 0°C to +50°C

• Storage Temperature: –20°C to +70°C

• Relative Humidity: 10–90% RH non-condensing
