YOKOGAWA ADM55-2 Relay Output Module

Product Description

• Type: Relay Output Module

• Brand: YOKOGAWA

• Model: ADM55-2

• Application: Designed for industrial automation systems, particularly for relay-based digital output control

• Mounting: Rack-mounted in relay I/O module nests

• Origin: Japan

• Warranty: 12 months

Technical Specifications

• Output Channels: 16-channel relay outputs

• Output Type: Relay contact (A and B contact configurations)

• Output Ratings:

• 250 V AC, 1.5 A or less

• 125 V DC, 0.1 A or less

• 24 V DC, 1.5 A or less

• Minimum Load: 5 V, 10 mA

• Relay Operation Time: ≤10 ms

• Relay Return Time: ≤10 ms

• Current Consumption: ≤2 A at 5 V DC

• Insulation Resistance: ≥10 MΩ at 500 V DC

• Withstanding Voltage:

• 1.5 kV between field device terminals and case

• 500 V between 24 V power terminals and case

• 1.5 kV between 24 V power terminals and field device terminals

• Operating Temperature: 0°C to 50°C

• Humidity Range: 10% to 90% RH (non-condensing)

• Weight: Approximately 136 g
