GE IS220PAOCH1B (IS230SNAOH2A) - Analog Input/Output Module

Specifications

• Part No.: IS220PAICH1B

• Manufacturer: General Electric

• Country of Manufacture: United States (USA)

• Product Type: Analog I/O Pack

• Series: Mark VIe

• Availability: In Stock

Functional Description

• GE’s IS220PAICH1B is an Analog I/O Pack designed for high-precision analog input and output functionality in Mark VIe turbine control systems

• Capable of processing up to 10 analog inputs:

• ±1 mA

• 0–20 mA

• 1–5 V DC

• ±5 V DC

• ±10 V DC

• 0–20 mA current loop

• Inputs 1–8 configurable for:

• Inputs 9–10 configurable for:

• Provides 2 current loop outputs (0–20 mA)

• PAICH2 version supports extended 0–200 mA output range on channel 1

• Design & Integration:

• Load terminal resistors located on terminal board

• Voltage sensed across resistors by PAIC circuitry

• Power input via 3-pin connector

• Data input through dual RJ45 Ethernet connectors

• Output via DC-37 pin connector directly linked to terminal board

• Visual diagnostics enabled by LED indicator lights

Characteristics

• Channels: 12 total (10 AI + 2 AO)

• Input Converter Resolution: 16-bit analog-to-digital conversion

• Scan Time:

• 5 ms normal scan rate (200 Hz)

• Max controller frame rate: 100 Hz

• Power Consumption:

• Typical: 5.3 W

• Worst case: 6.2 W
