GE DS3800NHVK1A1A High Voltage Board
GE DS3800NHVK1A1A High Voltage Board
Manufacturer: GE
Product No.: DS3800NHVK1A1A
Product Type: High Voltage Board
Product Origin: USA
Payment: T/T
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months
Product Overview
The GE DS3800NHVK1A1A is a high-voltage control/power circuit board engineered for use in the GE Speedtronic Mark IV turbine control system. It plays a critical role in managing and conditioning high-voltage signals and power distribution within turbine control environments, ensuring robust operation in industrial applications such as gas & steam turbines, power plants, and heavy-duty drives. Designed for durability, signal isolation, and stable performance in harsh conditions, this PCB is compatible with GE Mark IV racks and control chassis.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | DS3800NHVK1A1A |
| Product Type | High Voltage Control / Power Board |
| System Compatibility | GE Speedtronic Mark IV Turbine Control System |
| Primary Function | Controls and distributes high-voltage signals for turbine automation and protection |
| Input Logic Voltage | 120 V AC/DC signals for control inputs |
| Output Voltage | Up to 240 V AC for relay outputs and power switching |
| Relay Components | 4 high-current relays (10 A @ 250 V AC rating) |
| Signal Isolation | Isolates low-voltage logic from high-voltage circuitry for safety |
| Indicators | Multiple status LEDs for relay operation & power indication |
| Connectors | Multi-pin high-current and logic connectors for chassis integration |
| Operating Temperature | –40 °C to +85 °C |
| Storage Temperature | –55 °C to +125 °C |
| Humidity Tolerance | Up to 95 % RH (non-condensing) |
| Dimensions | 100 mm × 80 mm × 20 mm |
| Weight | 0.2 kg (0.44 lb) |
| Mounting | Rack-mounted PCB, compatible with Mark IV control chassis |
| Expected Lifetime | >10 years under normal industrial operation |
| Country of Origin | USA |
