YOKOGAWA MAC2*B Multipoint Analog Control Card

Product Description

The YOKOGAWA MAC2*B Multipoint Analog Control Card is a high-performance signal processing module designed for precise analog control in industrial automation systems. It supports multiple analog input and output channels, ensuring efficient data acquisition and control for complex processes.

Technical Specifications

• Model: MAC2*B

• Type: Multipoint Analog Control Card

• Input/Output Channels: Supports multiple analog input and output channels

• Signal Compatibility: Compatible with analog signals for process control

• Communication: Enables high-speed data communication for real-time control

• Redundancy: Supports dual-redundant configurations for enhanced system reliability

• Operating Temperature: -40°C to +70°C (-40°F to +158°F)

• Power Supply: 24 V DC ±10%

• Insulation Resistance: 100 MΩ or more at 500 V DC (between input, output, power supply, ground, and CN1-CN2)

• Withstand Voltage:

• 1500 V AC/min (between input and output, power supply, ground, CN1-CN2)

• 500 V AC/min (between output, power supply, ground, CN1-CN2)

• Signal Processing:

• Analog Input/Output: 8 points per channel

• Compatible with FIO modules of CENTUM VP/CS3000

• Mechanical Specifications:

• Weight: Approx. 3.8 kg

• Mounting Method: Rack or wall mounting (horizontal orientation only)

• Mounting Screws: M5 screws × 4

• Connectivity:

• Terminal Type: M4 screw terminals for I/O signals

• Shield Connection: M3 screw terminal for I/O cable shield

• Communication Terminals: RS-485 interface
