HONEYWELL 2MLQ-TR4B 32-Point Transistor Output Module
HONEYWELL 2MLQ-TR4B 32-Point Transistor Output Module
Manufacturer: HONEYWELL
Product No.: 2MLQ-TR4B
Product Type: Transistor Output Module
Product Origin: USA
Payment: T/T
Weight: 100g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The Honeywell 2MLQ-TR4B is a high-performance 32-point transistor output module designed for fast, reliable switching in industrial automation systems. It supports DC12/24V output applications and uses photo-coupler isolation to enhance noise immunity and protect the control circuitry. With compact design, low power consumption, and rapid response times of 1 ms or less, the module is suitable for driving a wide range of loads such as lamps, relays, and small actuators. Its 40-pin connector interface ensures easy wiring, while status LEDs provide clear operational monitoring for each output point.
Specifications
| Item | Description |
|---|---|
| Output Points | 32 points |
| Isolation Method | Photo-coupler isolation |
| Rated Load Voltage | DC 12 / 24 V |
| Load Voltage Range | DC 10.2 ~ 26.4 V |
| Max. Load Current | 0.1 A per point; 2 A per COM |
| Off Leakage Current | 0.1 mA or less |
| Max. Inrush Current | 4 A / 10 ms or less |
| Max. On-State Voltage Drop | DC 0.3 V or less |
| Surge Absorber | Zener diode (compliant with IEC 61006-6-2) |
| Response Time (Off → On) | 1 ms or less (rated resistive load) |
| Response Time (On → Off) | 1 ms or less (rated resistive load) |
| Common Method | 32 points / 1 COM |
| Current Consumption | 130 mA (when all points are ON) |
| External Voltage | DC 12/24 V ±10% (ripple ≤ 4 Vp-p) |
| Power Supply Current | 10 mA or less (DC24V connection) |
| Operation Indicator | LED ON when output is ON |
| External Connection | 40-pin connector |
| Suitable Cable Size | 0.3 mm² |
| Weight | 0.1 kg |
