BENTLY NEVADA 16699-10-02-01 Velocity Seismoprobe

Description

The Bently Nevada 16699-10-02-01 Velocity Seismoprobe is engineered to precisely measure casing vibration and structural velocity in rotating equipment. Delivering an electrical signal proportional to vibration velocity, it supports dependable machinery condition monitoring and protection. Encased in robust stainless steel, this sensor is ideal for harsh industrial applications including turbines, compressors, pumps, and motors.

Technical Specifications

• Sensor Type: Velocity Seismoprobe (velocity transducer)

• Sensitivity: 100 mV/mm/s ±5%

• Frequency Range: 4.5 Hz to 2,000 Hz (±3 dB)

• Measurement Range: ±38 mm/s (±1.5 in/s) peak

• Resonant Frequency: > 4.5 kHz

• Transverse Sensitivity: ≤ 5% of axial sensitivity

• Output Impedance: 350 Ω nominal

• Operating Temperature Range: −29°C to +100°C (−20°F to +212°F)

• Case Material: Stainless Steel

• Weight: Approximately 250 g (0.55 lb)

• Mounting Method: ¼-28 UNF stud mount

• Connector Type: MIL-C-5015 2-pin connector

• Power Supply: Passive device (self-generating, no external power source required)

Part Number Breakdown: 16699-10-02-01
