Yokogawa ATSA3D-0 Terminal Block Module
Yokogawa ATSA3D-0 Terminal Block Module
Manufacturer: Yokogawa
Product No.: ATSA3D-0
Product Type: Terminal Block Module
Product Origin: Japan
Payment: T/T
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
Description
The Yokogawa ATSA3D-0 is a specialized terminal block module designed to provide secure, organized, and reliable field wiring termination for analog input signals in industrial control systems. It’s commonly used with Yokogawa analog input I/O modules (such as ASI133) in distributed control systems (DCS) like CENTUM VP, CS 3000 FIO, and certain FA-M3 configurations. The module features dual-redundant signal paths and pressure clamp connections that ensure robust wiring in demanding process environments, simplify installation, and support intrinsically safe circuitry when used with appropriate barriers. Its compact form factor helps optimize cabinet space while maintaining easy access for field wiring and maintenance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ATSA3D-0 |
| Module Type | Terminal Block Module |
| Function | Analog input signal termination with secure field wiring |
| Number of Channels | 8 analog input channels (dual-redundant signal paths) |
| Compatible I/O Module | Works with Yokogawa ASI133 analog input modules |
| System Compatibility | Yokogawa CENTUM VP, CS 3000 FIO, FA-M3 PLC systems |
| Surge Absorber | Not included (fixed configuration) |
| Pressure Clamp Terminal | Yes, for vibration-resistant and tool-free connections |
| Safety Compliance | Supports intrinsically safe circuits (with proper barriers) |
| Environmental Standard | ISA S71.04 Class G3 |
| Operating Temperature | –20 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity Range | 5–95% RH, non-condensing |
| Dimensions (W × H × D) | 65.6 mm × 72 mm × 114 mm |
| Weight | 0.30 kg |
