Woodward 8901-457 Frequency-To-Voltage Signal Converter

Product Description

• The Woodward 8901-457 Converter is a frequency-to-voltage signal converter used in turbine and engine control systems.

• It converts AC voltage or frequency signals from magnetic pickups, tachometers, or other rotational speed sensors into standardized DC voltage signals suitable for controllers and monitoring systems.

• Designed for industrial and power generation environments, it provides precise, reliable signal conversion for accurate speed measurement and control.

• The module is rugged and built to withstand vibration, temperature extremes, and harsh operating conditions.

Technical Specifications

• Part Number: 8901-457

• Module Type: Frequency-to-Voltage Converter

• Input Signal: AC voltage from magnetic pickup or tachometer, typically 0.5–20 V peak-to-peak

• Input Frequency Range: 1 Hz to 10 kHz

• Output Signal: DC voltage, proportional to input frequency (e.g., 0–10 VDC for full-scale input)

• Output Load Capacity: Minimum 1 kΩ load, standard 10 kΩ recommended

• Power Supply: 24 VDC nominal

• Power Consumption: Approximately 5 W

• Response Time: < 10 ms

• Operating Temperature Range: –40 °C to +85 °C

• Storage Temperature Range: –50 °C to +100 °C

• Relative Humidity: 0% to 95%, non-condensing

• Mounting: Panel or chassis-mounted with secure mechanical fixing

• Dimensions: Approx. 120 mm × 80 mm × 40 mm

• Weight:  0.4 kg

• Applications: Engine speed measurement, turbine monitoring, generator synchronization, and process control systems requiring frequency-to-voltage conversion
