GE IS220PDIOH1B（IS230TNDSH2A) IO PACK, DISCRETE IO
GE IS220PDIOH1B（IS230TNDSH2A) IO PACK, DISCRETE IO
Manufacturer: GE
Product No.: IS220PDIOH1B（IS230TNDSH2A)
Product Type: IO PACK
Product Origin: USA
Payment: T/T
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months
Description
IS220PDIOH1B is an I/O pack that is part of the GE Speedtronic MKVIe gas turbine control.Discrete I/O pack IS220PDIOH1B with terminal boards(accessories) combinations are approved for use in hazardous locations.
The Ambient temperature rating is from -30 to +65 degrees celsius (-22 to +149 degrees Fahrenheit).
The Mark VIe control system is a versatile platform that can be used in a wide range of applications. It supports simplex, dual, and triple-redundant systems with high-speed, networked input/output (I/O).
For programming, configuration, trending, and analysis of diagnostics, the ControlST software suite is utilized with Mark VIe controls and related systems.
SPECIFICATIONS
| Item | Details |
|---|---|
| Part Number | IS220PDIOH1B / Compatible with IS230TNDSH2A Terminal Board |
| Product Name | Discrete I/O Pack |
| Manufacturer | General Electric (GE) |
| Series | Mark VIe |
| Product Type | Discrete Input/Output Pack |
| System Usage | GE Speedtronic Mark VIe Gas Turbine Control |
| Hazardous Location Rating | Approved when used with specified terminal boards |
| Ambient Temperature Rating | –30°C to +65°C (–22°F to +149°F) |
| Supported System Architectures | Simplex, Dual, and Triple-Redundant |
| Software Tool | ControlST for configuration, diagnostics, and trending |
TECHNICAL PARAMETERS
| Parameter | Details |
|---|---|
| Compatible Terminal Board | IS230TNDSH2A (TNDS) Discrete I/O Terminal Board |
| Input/Output Capability | Supports mixed discrete inputs and outputs depending on terminal board configuration |
| Discrete Inputs | 24 channels typical (dry contact sensing) |
| Discrete Outputs | Up to 12 relay-driving outputs (terminal board dependent) |
| Input Voltage Levels | Nominal 24 VDC, with support for 48 VDC / 125 VDC excitation (varies by board) |
| Input Threshold | “ON” detection typically above 16–18 VDC |
| Output Type | Relay coil drive or solid-state output via terminal board interface |
| Output Current Capacity | Up to 0.5 A per output (via terminal board) |
| Ethernet Ports | 2 × RJ-45 (10/100 Mbps), independent or redundant |
| Protocol | Mark VIe I/O Network (SRTP-based GE protocol) |
| Internal Processor | Mark VIe standardized I/O processor board |
| Acquisition Board Function | Handles discrete input scanning & output actuation logic |
| Logic Power Supply | 28 VDC typical supplied through I/O carrier |
| Field Power Requirement | External 24/48/125 VDC depending on terminal board |
| Isolation | Galvanic isolation between channels and system ground |
| Diagnostics | Continuous channel health detection, open/short input detection, relay feedback monitoring |
| Indicators | Module health LED, Ethernet link/activity LEDs, I/O status LEDs |
| Response Time | <1 ms input scan and output command response typical |
| Safety / Hazard Protection | ESD protection, transient/surge suppression |
| Operating Humidity | 5–95% non-condensing |
| Storage Temperature | –40°C to +85°C |
| Mounting | DIN-rail or pack carrier depending on system configuration |
| Dimensions | Approx. 8.26 cm (H) × 4.19 cm (W) × 12.1 cm (D) |
| Weight | 0.30 kg |
