Bachmann MPC265 Processor Module

Product Description

The Bachmann MPC265 is a high-performance processor module designed for industrial automation systems. It ensures reliable operation and supports complex control applications in demanding environments.

Technical Specifications

• Model Number: MPC265

• Manufacturer: Bachmann

• Type: Processor Module

• Processor Speed: 400/650/700 MHz (Pentium-class)

• Memory:

• SRAM: Up to 512 KB (battery-backed)

• FRAM: 64 KB (no battery required)

• DRAM: 64 MB or 128 MB

• Flash Storage: 8 MB internal

• Interfaces:

• USB: 1 port

• RS232: 1 port

• RS232/422/485: 1 port

• Ethernet: 10/100 Mbps

• CAN Bus: 1 port

• Expansion Slots:

• PCC201/xx

• CF200/xx

• Operating Temperature: -40°C to +70°C

• Power Supply: Integrated, 17 W for additional I/O modules

• Mounting: Standard M1 controller system form factor

• Weight: 520 g

• Origin: Austria

• Warranty: 12 months
