ABB SDCS-IOE-2 I/O Expansion Board
ABB SDCS-IOE-2 I/O Expansion Board
Manufacturer: ABB
Product No.: SDCS-IOE-2
Product Type: Expansion Board
Product Origin: Sweden
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The ABB SDCS-IOE-2 is an I/O expansion board designed for ABB DC drive control systems, mainly used with DCS500 and DCS600 series drives. It extends the available digital and analog input/output capacity of the drive, allowing more field signals such as limit switches, sensors, interlocks, and external control commands to be connected. The board enables flexible system integration, improves drive-to-plant communication, and supports advanced motor control, protection, and automation functions in industrial applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | I/O Extension Board |
| Model | SDCS-IOE-2 |
| System Compatibility | ABB DCS500 and DCS600 DC drive systems |
| Function | Expansion of digital and analog I/O for drive control |
| Supply Voltage | 24 V DC (from drive control system) |
| Digital Inputs | 8 channels, 24 V DC, opto-isolated |
| Digital Outputs | 6 channels, 24 V DC, transistor type |
| Analog Inputs | 2 channels, 0–10 V or 4–20 mA |
| Analog Outputs | 2 channels, 0–10 V |
| Input Signal Resolution | 12 bit (analog channels) |
| Output Load (Digital) | Max. 0.5 A per channel |
| Isolation Voltage | 500 V between I/O and control electronics |
| Communication with Control Board | Internal drive bus |
| Protection Class | IP20 |
| Mounting | Plug-in module on drive control rack |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Typical Applications | DC motor control, process automation, feedback and interlock handling |
