Honeywell SC-PCMX01 51307195-175 Programmable Controller Module

Product Description

The Honeywell SC-PCMX01 51307195-175 is a Programmable Controller Module designed for integration within the RTU2020 platform, serving as the primary control unit for remote monitoring and automation applications. This module supports field-deployable mixed I/O configurations and delivers robust processing capabilities for real-time control tasks in oil & gas, utilities, and industrial automation environments. It is optimized for distributed architectures requiring flexibility, reliability, and reduced installation costs.

Technical Specifications

• Model: SC-PCMX01

• Part Number: 51307195-175

• Function: Programmable Controller Module for RTU2020

• Processor: ARM Cortex-A8, 400 MHz

• RAM: 128 MB

• Flash Memory: 256 MB

• Power Input: 24 VDC ±20%

• Power Consumption: Approx. 10 W

• Digital Inputs: Up to 16 channels, 24 VDC

• Digital Outputs: Up to 12 channels, 24 VDC, max 0.5 A/channel

• Analog Inputs: 8 channels, 16-bit resolution, 0–10 V or 4–20 mA

• Analog Outputs: 4 channels, 12-bit resolution, 4–20 mA

• Communication Interfaces:

• 2 × RS-485

• 1 × RS-232

• 1 × Ethernet 10/100 Mbps

• 1 × CAN

• Supported Protocols: Modbus RTU, Modbus TCP, DNP3

• Scan Time: ~5 ms for 1000 I/O points

• Mounting Type: DIN rail or base-mounted in RTU2020 chassis

• Operating Temperature: –40°C to +70°C

• Humidity: 5% to 95% RH, non-condensing

• Shock Resistance: 30 g, 11 ms

• Vibration Resistance: 5 g, 10–500 Hz

• Protection Features: Surge and EMI protection

• Dimensions: Approx. 263 mm × 58 mm × 28 mm

• Weight: 0.4 kg
