Honeywell 51153998-100 I/O Interface Module

Product Description

• The Honeywell 51153998-100 is an I/O interface module designed for Honeywell TDC 3000 and Experion control systems.

• It serves as a communication link between field devices and the controller, ensuring accurate signal processing and reliable system integration.

• The module is built for high stability in industrial automation, supporting continuous operation in demanding process environments.

• It provides secure mounting in Honeywell standard chassis and offers robust electrical isolation for improved safety.

Technical Specifications

• Part Number: 51153998-100

• Module Type: I/O Interface Module

• Input/Output Capacity: 16 channels (configurable for digital or analog depending on system requirements)

• Signal Type: Supports 24 VDC digital signals or 4–20 mA analog signals

• Power Supply Voltage: 24 VDC nominal

• Current Consumption: Approximately 6–8 W

• Isolation: Channel-to-channel and channel-to-system isolation for noise immunity

• Operating Temperature Range: 0 °C to +60 °C

• Storage Temperature Range: –40 °C to +85 °C

• Relative Humidity: 5% to 95% non-condensing

• Response Time: Typically < 5 ms

• Dimensions: Approx. 233 mm × 105 mm (standard Honeywell module size)

• Weight: 0.3–0.5 kg

• Mounting: Rack-mounted within Honeywell system chassis

• Application Areas: Distributed control systems, process monitoring, signal interfacing between field devices and controllers
