HONEYWELL 2MLI-D24A 32-Point DC24V Input Module

Product Description

HONEYWELL 2MLI-D24A is a 32-point DC24V Input Module designed for industrial automation applications. It provides photo coupler isolation for reliable signal processing and ensures fast response times for precise control. This module is widely used in PLC systems for high-speed digital input monitoring.

Technical Specifications

• Input Points: 32

• Isolation Method: Photo coupler isolation

• Rated Input Voltage: DC24V

• Rated Input Current: ~4 mA

• Operation Voltage Range: DC20.4~28.8V (ripple rate < 5%)

• On Voltage/Current: DC19V or higher / 3 mA or higher

• Off Voltage/Current: DC11V or lower / 1.7 mA or lower

• Input Resistance: ~5.6 kΩ

• Response Time:

• Off to On: 1ms/3ms/5ms/10ms/20ms/70ms/100ms (set by CPU parameter)

• On to Off: 1ms/3ms/5ms/10ms/20ms/70ms/100ms (set by CPU parameter)

• Default: 3ms

• Isolation Voltage: AC560V rms/3 Cycle (altitude 2000m)

• Isolation Resistance: 10 MΩ or more by megger

• Common Method: 32-point / COM

• Current Consumption: 50 mA

• Operation Indicator: Input On, LED On

• External Connection Method: 40-point connector

• Weight: 0.1 kg
