HIMA X-DI 32 01 Digital Input Module
HIMA X-DI 32 01 Digital Input Module
Manufacturer: HIMA
Product No.: X-DI 32 01
Product Type: Digital Input Module
Product Origin: GERMANY
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The X-DI 32 01 digital input module is designed to evaluate up to 32 digital input signals.
Its 24 V current-sinking logic inputs comply with IEC 61131-2 standards.
A 24 VDC power supply for proximity switches or contacts is provided for every four inputs.
Product Data
| Parameter | Specification |
|---|---|
| Operating voltage | 24 VDC |
| Current input (module) | Minimum 600 mA (without channels/proximity switch supplies); Maximum 1.5 A (with 32 channels and proximity switch supplies) |
| Number of channels | 32, non-galvanically isolated |
| Rated input voltage | 0 … 24 V |
| Switching point (typical) | 9.3 V ±0.4 V (2.1 mA ±0.15 mA) |
| Voltage level – low | –3 … 5 V |
| Voltage level – high | 11 … 30 V |
| Input current operating range | –3 … 30 V (current limited to approx. 2.5 mA) |
| Additional current input per channel | Minimum < 3 mA (without proximity switch supply); Maximum 25 mA (with proximity switch supply) |
| Number of proximity switch supplies | 8 with 4 outputs each |
| Output voltage for proximity switch supply | Operating voltage less 2.5 V |
| Output current of the proximity switch supply | 100 mA for each group, short-circuit-proof |
| Housing material | Polyamide (fire-retardant in accordance with NFPA 72) |
| Operating temperature | 0 °C to +60 °C |
| Storage temperature | –40 °C to +85 °C |
| Humidity | Max. 95% relative humidity, non-condensing |
| Type of protection | IP20 |
| Protection class | III in accordance with IEC/EN 61131-2 |
