GE Multilin UR7CM UR-7CM Single-Mode Module
GE Multilin UR7CM UR-7CM Single-Mode Module
Manufacturer: GE
Product No.: UR7CM
Product Type: Single-Mode Module
Product Origin: USA
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Description
The UR7CM (UR-7CM) is a fiber-optic communications interface module designed for the Universal Relay (UR) series protection and control platform. It enables reliable, high-speed data transmission over single-mode optical fiber for long-distance communications between protection devices in substations, automation networks, and distributed power system architectures. The module supports 1300 nm wavelength single-mode fiber with SC/APC-style connectors, delivering efficient, low-loss communications up to extended ranges. It is engineered for rugged industrial environments with wide operating temperature tolerance and seamless integration into GE Multilin UR rack systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | UR7CM UR-7CM Single-Mode Module |
| Wavelength | 1300 nm |
| Fiber Type | Single-mode optical fiber |
| Transmission Distance | Up to ~10 km |
| Data Rate | Up to ~1 Gbps |
| Connector Type | SC/APC |
| Power Consumption | < 2 W |
| Operating Temperature | −40 °C to +70 °C |
| Storage Temperature | −40 °C to +85 °C |
| Dimensions | ~140 mm × 110 mm × 45 mm |
| Mounting | Plug-in module for GE Multilin UR chassis |
| Origin | USA |
