GE IC695CPL410-AAAC Rackless Edge Controller
GE IC695CPL410-AAAC Rackless Edge Controller
Manufacturer: GE
Product No.: IC695CPL410-AAAC
Product Type: Rackless Edge Controller
Product Origin: USA
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Product Description
-
The IC695CPL410-AAAC is a rackless edge controller from the PACSystems RX3i family.
-
It combines real-time deterministic PLC control with integrated Linux capabilities.
-
Designed for industrial Internet-of-Things applications, data logging, visualization, cloud/edge analytics, and redundancy/high-availability options.
Technical Specifications
| Specification Category | Details |
|---|---|
| Model Number | IC695CPL410-AAAC |
| Controller Family | PACSystems RX3i |
| Processor | Quad-core AMD G Series, 1.2 GHz |
| Memory (PLC real-time part) | 64 MB RAM for PLC logic |
| Non-volatile Flash (PLC part) | 64 MB flash |
| Linux / Edge Module | Embedded Linux (Ubuntu 16.04 LTS) with root access |
| Edge Module Memory / Storage | Approx. 2 GB RAM; ~50 GB SSD / internal storage |
| Display | OLED display |
| Power Requirements | Input Voltage: 18-30 V DC; Max Power Consumption: ~20 Watts |
| Communications / Ports | Multiple Gigabit Ethernet ports (including one dedicated to Linux), USB 3.0 (USB-A) ports, serial RS-232 interface |
| Protocol Support | PROFINET, OPC-UA (server), Modbus TCP, Ethernet Global Data, HART pass-through, etc. |
| Environmental Operating Range | -40 °C to +70 °C |
| Environmental Storage Range | -40 °C to +85 °C |
| Physical Size / Mounting | Rackless CPU style; dimensions approximately 203.5 mm × 56.7 mm × 153.6 mm |
| Backup / Energy Pack | Uses an energy pack (model IC695ACC403) for memory backup in case of power loss |
| Firmware / Software Features | Secure boot, Trusted Platform Module (TPM), integrated PACEdge software, support for WebHMI |
