HIMA
187 persediaan
HIMA F-7541 F7541 Digital Input Module
HIMA F-7541 F7541 Digital Input Module
Manufacturer: HIMA
Product No.: F7541
Product Type: Digital Input Module
Product Origin: Germany
Payment: T/T
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The HIMA F-7541 is a digital input module designed for use in safety-related control and automation systems.
It acquires discrete (on/off) signals from field devices and transmits them to the logic system with high reliability.
The module supports multiple input channels, flexible operating voltages, and is built for robust operation in industrial environments.
Technical Data
| Parameter | Specification |
|---|---|
| Model | F-7541 |
| Type | Digital Input / Coupling Module |
| Operating Voltage | 5 VDC or 24 VDC |
| Current Consumption | 600 mA at 5 VDC; 750 mA at 24 VDC |
| Number of Input Channels | 8 or 16 digital input channels |
| Connection Type | Relay interface |
| Communication Interface | RS-485 |
| Operating Temperature | −20 °C to +55 °C |
| Storage Temperature | −40 °C to +85 °C |
| Dimensions (H × W × D) | 210 × 130 × 30 mm |
| Weight | 0.15–0.20 kg |
