GE DS200CDBAG1BDB Contactor Driver Board
GE DS200CDBAG1BDB Contactor Driver Board
Manufacturer: GE
Product No.: DS200CDBAG1BDB
Product Type: Contactor Driver Board
Product Origin: USA
Payment: T/T
Weight: 1200g
Shipping port: Xiamen
Warranty: 12 months
Product Description
The DS200CDBAG1BDB Contactor Driver Board opens and closes contactors in GE turbine and drive systems, providing power and control signals under the command of associated power supply or instrumentation boards. It features configurable jumpers for coordinated multi-board operation, status indicators (e.g., LEDs), and a modular design that simplifies maintenance and replacement. Typical contactor coil voltages for use with this board range from 30 V DC to 40 V DC.
Technical Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model Number | DS200CDBAG1BDB |
| Product Type | Contactor Driver Board (CDBA) |
| Series | Mark V Speedtronic |
| Function | Drive control of contactors in turbine/drive systems |
| Control/Input Voltage | 24 V DC supply (logic) |
| Contactor Coil Voltage | 30–40 V DC |
| Switching Output | Multiple contactor control channels |
| Current Capacity | Up to ~5 A continuous (per channel) |
| Protection Features | Over-voltage and short-circuit protection |
| Indicators | LED status indicators for channel/board operation |
| Jumpers | Two jumpers — one factory set and one configurable for coordinated operation |
| Board Revision | Functional Revision B, Sub-revision DB |
| Mounting | Rack-mounted PCB assembly |
| Dimensions | Approx. 203 × 160 × 89 mm (board frame) |
| Weight | ~0.45 – 1.2 kg (varies by supplier packaging) |
| Operating Temperature | Industrial range (typical) –40 °C to +70 °C |
| Communication Interface | RS-485 (for control data interfaces) |
| Country of Origin | USA |
