YOKOGAWA ADV151-P13 Analog Input Module

Product Description

The YOKOGAWA ADV151-P13 is an analog input module used in the Yokogawa CENTUM CS 3000 and CENTUM VP distributed control systems. It is designed to receive multiple analog input signals (such as 4–20 mA) from field instruments and convert them into digital data for monitoring and control. The module ensures high accuracy, channel isolation, and noise immunity, making it ideal for critical process control applications.

Technical Specifications

• Model: ADV151-P13

• Function: Analog input module

• Input Type: 4–20 mA DC (current input)

• Number of Channels: 16 isolated channels

• Resolution: 16-bit A/D conversion

• Input Signal Range: 0 to 24 mA

• Input Resistance: 250 Ω (external precision resistor)

• Channel Isolation: Channel-to-channel and channel-to-ground isolation

• Accuracy: ±0.1% of full scale

• Sampling Cycle: 100 ms for all channels

• Connection Type: Terminal block (external wiring)

• Power Supply: 5 VDC (supplied via baseplate)

• Mounting: Mounted on I/O base unit

• Operating Temperature: 0 to 50°C

• Storage Temperature: -20 to +70°C

• Humidity Range: 5% to 95% RH (non-condensing)

• Dimensions: Approx. 130 mm (H) × 30 mm (W) × 170 mm (D)

• Weight: 0.4 kg
